SDL - Simple DirectMedia Layer

Download & Compile

% sudo apt-get install libsdl1.2-dev

• http://www.libsdl.org/

SDL.lib SDLmain.lib opengl32.lib

g++ `sdl-config --cflags --libs` -lGL sample.cpp -o sample

cmake準備

• CMakeLists.txt

#
# CMakeFileLists.txt
#
# > cmake .
#

# 要求するCMakeのバージョン
cmake_minimum_required(VERSION 2.6)

# build type
set(CMAKE_BUILD_TYPE DEBUG)

# compile option (DEBUG)
set(CMAKE_CXX_FLAGS_DEBUG "-g -Wall")
set(CMAKE_C_FLAGS_DEBUG "-g -Wall")

# compile option (Release)
set(CMAKE_CXX_FLAGS_RELEASE "-Wall -O3")
set(CMAKE_C_FLAGS_RELEASE "-Wall -O3")

# インストール先
# CMAKE_INSTALL_PREFIX(...)


############################################################

set(PROJ_NAME run.x)
set(TARGET ${PROJ_NAME})

set(SDL_PATH /usr)

# プロジェクト名
project(${PROJ_NAME})

# インクルードパスの追加
include_directories(${SDL_PATH}/include)

# ライブラリパスの追加
link_directories(${SDL_PATH}/lib)

# 実行ファイルとソースファイル群
add_executable(${TARGET} main.cpp)

# ライブラリ
target_link_libraries(${TARGET} SDL GL GLU)

# マクロ設定 [-D]
#add_definitions(-D)


Empty Project

• main.cpp

#include <cstdio>
#include <cstdlib>
#include <iostream>

#include <SDL/SDL.h>
#include <SDL/SDL_opengl.h>

#include <GL/gl.h>
#include <GL/glu.h>

static bool initSDL(int width, int height);
static void initGL();
static void reshape(GLsizei w, GLsizei h);
static void process_events();
static void draw();

bool initSDL(int width, int height)
{
  const SDL_VideoInfo* info;
  const SDL_Surface *surf;
  int bpp = 0;

  if (SDL_Init(SDL_INIT_VIDEO) < 0) {
    std::cerr << "Video initialization Failed : " << SDL_GetError() << "\n";
    SDL_Quit();
    return false;
  }
  info = SDL_GetVideoInfo();
  if (!info) {
    std::cerr << "Video query failed : " << SDL_GetError() << "\n";
  }
  bpp = info->vfmt->BitsPerPixel;

  SDL_GL_SetAttribute(SDL_GL_RED_SIZE,8);
  SDL_GL_SetAttribute(SDL_GL_GREEN_SIZE,8);
  SDL_GL_SetAttribute(SDL_GL_BLUE_SIZE,8);
  SDL_GL_SetAttribute(SDL_GL_ALPHA_SIZE,8);
  SDL_GL_SetAttribute(SDL_GL_DEPTH_SIZE,24);
  SDL_GL_SetAttribute(SDL_GL_STENCIL_SIZE,8);
  SDL_GL_SetAttribute(SDL_GL_DOUBLEBUFFER,1);

  //atexit(SDL_Quit);
  surf = SDL_SetVideoMode(width, height, bpp, SDL_OPENGL|SDL_RESIZABLE);
  if (!surf) {
    std::cerr << SDL_GetError() << "\n";
    SDL_Quit();
    return false;
  }

  reshape(width, height);

  return true;
}


void initGL()
{
  glClearColor(0.0, 0.0, 0.0, 0.0);
  glEnable(GL_DEPTH_TEST);
}

void reshape(GLsizei w, GLsizei h)
{
  glViewport(0, 0, w, h);

  glOrtho(0.0, w, h, 0.0, -1.0, 1.0);
}

void process_events()
{
  SDL_Surface *surf;
  SDL_Event event;
  while (SDL_PollEvent(&event)) {
    switch (event.type) {
    case SDL_QUIT:
      std::exit(1);
      break;

    case SDL_KEYDOWN:
      switch (event.key.keysym.sym) {
      case SDLK_ESCAPE: std::exit(0);
        break;
      default:
        break;
      }
      break;

    case SDL_VIDEORESIZE:
      SDL_FreeSurface(surf);
      surf = SDL_SetVideoMode(event.resize.w, event.resize.h, 32, SDL_OPENGL|SDL_RESIZABLE);
      reshape(static_cast<GLsizei>(event.resize.w), static_cast<GLsizei>(event.resize.h));
      break;
    }
  }
}

void draw()
{
  glClear(GL_COLOR_BUFFER_BIT | GL_DEPTH_BUFFER_BIT);

  //glLoadIdentity();

  // 四角形を描く
  glBegin(GL_QUADS);
  {
    glColor3f(1.0, 1.0f, 1.0); // white
    // 4つの頂点を指定
    glVertex3f(100.0f, 100.0f, 0);
    glVertex3f(540.0f, 100.0f, 0);
    glVertex3f(540.0f, 380.0f, 0);
    glVertex3f(100.0f, 380.0f, 0);
  }
  glEnd();

  SDL_GL_SwapBuffers();
}


int main(int argc, char* argv[])
{
  if (!initSDL(640, 480)) {
    std::exit(1);
  }

  // initialize OpenGL
  initGL();

  // simLoop
  while (true) {
    process_events();
    draw();
  }

  return 0;
}


表示

参考

http://www.tacoworks.jp/software/SDLdoc-jp/html/index.html
