概要
33,45,78回転、±20%のピッチコントロールなど
T-2000より性能が向上している。多分ハンピン製OEM。
スペック表
Turntable section:
High torque platter motor, Start/Stop button, High torque braking, 33 1/3, 45, 78rpm speeds, forward and reverse platter direction, pop-up stylus target light, Quartz look of 0% speed position, 45 rpm adapter and holder, Extra stylus holder, adjustable feet for levelling and easily removable smoked plastic lid.
Type/ Speeds: 3-speed 33 1/3, 45 and 78 rpm, full manual
Pitch Controls: +/- 10%, +/- 20%
Motor: 8 pole, 3 phase, brushless DC motor
Driving Method: Direct drive
Platter: 330 mm. diam, Alu diecast
Wow and Flutter: Less than 0,2% WRMS (JIS WTD) with 33 1/3 rpm
S/N Ratio: More than 50dB (DIN-B)
Starting Torque: More than 1.6 Kgf.cm
Starting/Braking: Less than 1 sec. (Electronic Brake) Forward and reverse platter direction
Speed Change: Less than 1 sec. From 33 1/3 to 45, 45 to 33 1/3 and 33 1/3 to 78 rpm
High of cue: (first track) 8-10.5mm
Descend of que: Less than 5 sec.
Pitch output:675+/-1Hz (pitch control set 0%) with 33 1/3 rpm
Tonearm Section:
Shaped tone arm assembly with counterweight, high adjustment, scating adjustment, height lock, lever lift with height adjustment and tone arm holder with lockingmechanism.
Type: Static balanced S-shaped with detachable headshell
Effective Arm length:234mm
Overhang: 20mm
Tracking Error Angle: Less than 3 degree Tracking Force
Adjustment Range: 0-4g
Applicable Cartridge
Weight: 6-10g
Anti-scating Range: 0-7g
Powersupply:AC 230V, 50Hz
Power Consumption:25 Watt
Dimensions LxWxH:450 x 352 x 148,5 mm
Weight:10,6 Kg
価格
最終更新：2019年02月14日 23:55
