typedef struct tagMQMD MQMD;
struct tagMQMD {
MQCHAR4 StrucId; /* Structure identifier */
MQLONG Version; /* Structure version number */
MQLONG Report; /* Options for report messages */
MQLONG MsgType; /* Message type */
MQLONG Expiry; /* Message lifetime */
MQLONG Feedback; /* Feedback or reason code */
MQLONG Encoding; /* Numeric encoding of message data */
MQLONG CodedCharSetId; /* Character set identifier of message
data */
MQCHAR8 Format; /* Format name of message data */
MQLONG Priority; /* Message priority */
MQLONG Persistence; /* Message persistence */
MQBYTE24 MsgId; /* Message identifier */
MQBYTE24 CorrelId; /* Correlation identifier */
MQLONG BackoutCount; /* Backout counter */
MQCHAR48 ReplyToQ; /* Name of reply queue */
MQCHAR48 ReplyToQMgr; /* Name of reply queue manager */
MQCHAR12 UserIdentifier; /* User identifier */
MQBYTE32 AccountingToken; /* Accounting token */
MQCHAR32 ApplIdentityData; /* Application data relating to
identity */
MQLONG PutApplType; /* Type of application that put the
message */
MQCHAR28 PutApplName; /* Name of application that put the
message */
MQCHAR8 PutDate; /* Date when message was put */
MQCHAR8 PutTime; /* Time when message was put */
MQCHAR4 ApplOriginData; /* Application data relating to
origin */
/* Ver:1 */
MQBYTE24 GroupId; /* Group identifier */
MQLONG MsgSeqNumber; /* Sequence number of logical message
within group */
MQLONG Offset; /* Offset of data in physical message
from start of logical message */
MQLONG MsgFlags; /* Message flags */
MQLONG OriginalLength; /* Length of original message */
/* Ver:2 */
};
